10 pairs LSA profile switching module with wire guide (TP-1241-10P) is used in the main distribution frames (MDF). It is highly reliable and cost-effective wire connection system for modern telecommunications and data networks.

It adopts IDC (Insulation Displacement Connection) technique, which means no soldering, wire-stripping or the use of screws, and which clamps the wires at a 45 degree angle, thus dramatically reducing the risk of a poor termination and increasing the wiring productivity. Contacts that ensure the highest degree of reliability even under the most adverse environmental and climatic conditions. A completely reliable, gas-tight connection between the contact and conductor.

10 pairs LSA profile switching modules use a normally open two piece contact, thus the MDF protector must be inserted into the module for continuity, and against over-votage over currentl meantime. A test cord can be inserted into a pair to test each side of the circuit independently. This greatly accelerates fault identification.
